6. Technical specifications
Particle detection range 0.3~10μm
Six-channel particle size 0.3，0.5，1.0，2.5，5.0，10um
PM2.5 Range 0～1000μg/m³
PM2.5 Precision 0~100μg/m³：±10μg/m³
100~1000μg/m³：±10%
Concentration resolution 1μg/m³
Number of particles output range ≤ 2000000 Granule/L
Flow 1 liter/min（2.83L=1L*2.83）
Cleanliness standard meets the ISO 14644-1 ISO5 level-ISO9 level
Response time 1 second
Temperature measurement range
Humidity measurement range 0～100％ RH
Humidity accuracy ±3％ RH
Humidity resolution 0.01％ RH
Power supply 3.7V Removable 18650 lithium battery
Charging voltage 5V/USB
Length of work 2000mAhCan work continuously≥9 hours
7. Common problem analysis
1. There is no data to show the number and concentration of particulate matter in the air
Analysis 1: The battery power is too low to start the sensor work
2. Doesn't boot
Analysis 1: If the battery is dead or damaged, use the USB port to supply power. If it can be
turned on and there is a change in the power grid in the upper right corner, the battery is dead.
If there is no change, only the OK icon will be displayed.
