DGFLOW DGB MV 30 - PRODUCT MODELS AND IDENTIFICATION CODES

19
PRODUCT MODELS AND IDENTIFICATION CODES
DGB MVF 75
Models MV and SV (1 variable speed pump)
model
MV 30 MV 55 MV 75
SV 30 SV 55 SV 75
Maximum motor rated power @ 400 V a.c.
kW
3.0 5.5 7.5
Maximum motor rated power @230 V a.c.
kW
1.7 3.0 4.0
Maximum current
A
8.0 14.0 18.0
input
Three-phase voltage
V
400 +/- 10% (230 +/- 10%)
frequency
Hz
50- 60
max nominal current
A
8.0 14.0 18.0
output
Three-phase voltage
V
400 (230)
frequency
Hz
0 --> 50- 60
max nominal current
A
8.0 14.0 18.0
Main circuit breaker nominal current
A
40 40 40
Thermal magnetic switch nominal current
A
- 13 --> 18 17 --> 23
Fuse module nominal current
A
10 - -
Models MVF (1 variable speed pump and 1 fixed speed pump)
model
MVF 30 MVF 55 MVF 75
Maximum motor rated power (single pump) @ 400 Va.c.
kW
3.0 5.5 7.5
Maximum motor rated power (single pump) @230 V a.c.
kW
1.7 3.0 4.0
Maximum current (single pump)
A
8.0 14.0 18.0
input
Three-phase voltage
V
400 +/- 10% (230 +/- 10%)
frequency
Hz
50- 60
max nominal current
A
16.0 28.0 36.0
output
(variable
speed pump)
Three-phase voltage
V
400 (230)
Frequency (variable speed pump)
Hz
0 --> 50- 60
max nominal current
A
8.0 14.0 18.0
output (fixed
speed pump)
Three-phase voltage
V
400
Frequency (fixed speed pump)
Hz
50- 60
max nominal current
A
8.0 14.0 18.0
Main circuit breaker nominal current
A
40 40 40
Thermal magnetic switch nominal current (inverter protection)
A
- 13 --> 18 17 --> 23
Fuse module nominal current (inverter protection)
A
10 - -
contactor nominal power (fixed speed pump protection)
kW
4.2 7.5 7.5
Product family (DGBOX)
Master / slave unit (M = master, S = slave)
First pump - variable speed (V)
Second pump – fixed speed (F)
Power in kW x 10 (ex. 75 = 7,5 kW)
