DGFLOW DGB MV 30 - MAIN MENU and PARAMETER MENU; BASE SETUP; ADVANCED CONFIGURATION (ADV SETUP); HARDWARE CONFIGURATION (HARDWARE SETUP)

8
MAIN MENU and PARAMETER MENU
highlighted below the parameters that must be configured for the proper functioning of DGBOX (case referred to a single pump)
Menu: BASE SETUP
Par. Parameter code Description u.m. Default Min Max Step
1.1 PRESSURE SET 1 P1 Working pressure 1 bar 3.5 0,5 P1S 0.1
1.2 PRESSURE SET 2 P2 Working pressure 2 bar 2.5 1.0 P1S 0.1
1.3 PUMP 1 CURRENT CU1
Nominal current pump n°1 A
8
-
14
-
18
1.0
8-14-18 0.1
1.4 PUMP 1 ROTATION RO1 Rotation direction of pump n° 1 - CW CW ACW -
1.5 PUMP 2 CURRENT CU2
Nominal current pump n°2
A
0
1.0 8-14-18 0.1
1.6 PUMP 2 ROTATION RO2 Rotation direction of pump n° 2 - CW CW ACW -
1.7 PUMP 3 CURRENT CU3
Nominal current pump n°3
A
0
1.0 8-14-18 0.1
1.8 PUMP 3 ROTATION RO3 Rotation direction of pump n° 3 - CW CW ACW -
1.9 PUMP 4 CURRENT CU4
Nominal current pump n°4
A
0
1.0 8-14-18 0.1
1.10 PUMP 4 ROTATION RO4 Rotation direction of pump n° 4 - CW CW ACW -
1.11 SERIAL -FIRMW -- Serial number and firmware version - - - - -
Menu: ADVANCED SETUP
Par. Parameter code Description u.m. Default Min Max Step
2.1 RESTART DIFF DPr Restarting differential pressure bar 0.4 0.1 1.0 0.1
2.2 MOTOR FREQ MF Motor frequency Hz 50 50 60 10
2.3 MIN FREQ LoF Minimum operating frequency Hz 30 15 40 1
2.4 MAX FREQ HiF maximum operating frequency Hz 50 40 70 1
2.5 MIN DRY PRES PD Minimum working pressure % 70 10 100 1
2.6 DRY RUN TIME TD Dry operating time before error of water lack s 10 0 100 1
2.7 MIN POWERF1 x Pump 1 minimum cosphi - 0,10 0 1,00 0,01
2.8 MIN POWERF2 x
Pump
2
minimum cosphi
- 0,10 0 1,00 0,01
2.9 MIN POWERF3 x
Pump
3
minimum cosphi
- 0,10 0 1,00 0,01
2.10 MIN POWERF4 x
Pump
4
minimum cosphi
- 0,10 0 1,00 0,01
2.11 POWERF TIME x Dry operating time before error of dry run s 4 0 15 1
2.12 DRY RUN RESTART TR
Time interval before restarting after error of water
lack
min 10 0 100 1
2.13 FLOW TIMEOUT TF Delay time before stopping s 5 1 15 1
2.14 RESPONSE FACTOR RF Inverter reactivity factor - 2 1 5 1
2.15 SWITCH FREQ SF Inverter switching frequency kHz 8 4 12 2
2.16 PRESSURE UNIT PU Pressure unit of measure - bar PSI bar -
2.17 ACCELERATION ACC variation of frequency Hz/s 25 10 40 1
2.18 OFF FREQ. SP1 OF1 Switch-off frequency with working pressure 1 Hz 40 Fmin
**
45 0.1
2.19 OFF FREQ. SP2 OF2 Switch-off frequency with working pressure 2 Hz 40 Fmin
**
45 0.1
2.20 KP KP P.I.D control proportional coefficient - 8 1 50 1
2.21 KI KI P.I.D control integrative coefficient 10 20 0 50 1
2.22 RESTORE DEFAULT - Restore of BASE and ADV parameters - - - - -
Menu: HARDWARE SETUP
Par.
Parameter code Description
u.m. Default Min Max Step
3.1 PUMP 1 CONFIG P1C
Pump 1 configuration
- 1 1 1 1
3.2 PUMP 2 CONFIG P2C
Pump
2
configuration
- 0 0 3 1
3.3 PUMP 3 CONFIG P3C
Pump 3
configuration
- 0 0 1 1
3.4 PUMP 4 CONFIG P4C
Pump 4
configuration
- 0 0 1 1
3.5 INPUT 1 CONFIG IN1 digital 1 input function set - 0 0 5 1
3.6 INPUT 2 CONFIG IN2 digital 2 input function set - 0 0 5 1
3.7 OUTPUT 1 CONFIG OU1 digital 1 output function set - 0 0 4 1
3.8 OUTPUT 2 CONFIG OU2 digital 2 output function set - 0 0 4 1
3.9 ANALOG 2 CONFIG AN2 Configuration of analogic input 2 - 0 4-20 4-20 -
