Operation
4.2.2
4.2.2 RM4V Recycling Cassette
4.2.2.1
4.2.2.1 Opening/Closing the Recycling Cassette
Opening
1
2
1
2
Figure4-9: RM4V-recycle cassette opening
1. Turn the cassette lever (1).
2. Open the cassette front cover (2).
Closing
1
Figure4-10: RM4V recycling cassette _closing cover
3. Close the front cover of the recycling cas-
sette.
