RING TERMINAL QUICK-CONNECT
The ring connectors permanently attach to the battery, providing easy access
to quickly connect the charger to your battery. This application is appropriate for
motorcycles, lawn tractors, ATVs and snowmobiles.
1. To permanently attach to a battery, loosen and remove each nut from the bolt
at the battery terminals.
2. Connect the red POSITIVE connector ring to the POSITIVE battery terminal.
3. Connect the black NEGATIVE connector ring to the NEGATIVE battery terminal.
4. Replace and tighten the nuts to secure.
5. Connect the cable to the end of the charger output cord.
Take care to keep the wires and plug away from metal and moving parts.
6. Plug the charger power cord into a grounded 120V AC electrical wall outlet.
7. Select the battery type.
8. When charging is complete, disconnect the AC cord from the outlet, and then
disconnect the quick-connect cable from the charger output cord.
12V ACCESSORY PLUG QUICK-CONNECT
Charge or maintain your battery without lifting the hood.
1. Connect the end of the 12V accessory plug quick-connect to the charger.
2. Insert the 12V accessory plug into the 12V accessory outlet.
3. Route the power cord from the charger through the vehicle’s open window.
4. Plug the charger power cord into a grounded 120V AC electrical wall outlet.
5. If the vehicle’s ignition key has to be on in order for the accessory outlet to
supply/receive power, turn the key, without starting the engine.
6. Select the battery type.
7. When charging is complete, disconnect the AC cord from the outlet, and then
remove the 12V accessory plug from the 12V outlet.
BATTERY CHARGING TIMES
APPLICATION
BATTERY
SIZE
CHARGING TIME (hours)
6A 10A 12A 15A
POWERSPORTS 6 Ah
32Ah
2 1.5 1 0.5
5 4 3 2
AUTOMOTIVE 300 CCA
1000 CCA
4 3 2 1.5
10 7 5.5 4
MARINE 50 Ah
105 Ah
5 3.5 2.5 2
11 8 6 5
Times are based on a 50% discharged battery and may change,
depending on age and condition of battery.
