Digi-Pas DWL3500XY User Manual

© 2017 DIGIPAS TECHNOLOGIES INC. All Rights Reserved.
CHAPTER 1: DEVICE OVERVIEW
Technical Specification
DWL3500XY
Measurement Range
(Single Axis Mode)
0.000° to ± 20.000°
Measurement Range
( 2-Axis Mode)
0.000° to ± 10.000°
Resolution
0.001° (≤20µm/M) (0.0002 in/ft)
Accuracy
± 0.001° at 0.000° ~ ± 2.000° (≤20µm/M)
(0.0002 in/ft) (3.6 arcsec.)
± 0.003° at other angle
Repeatability
0.001° (≤20µm/M) (0.0002 in/ft)
Cross Axis Error
Negligible (± 0.00025°)
Vibrometer (Relative g)
2.0
Display
Colour TFT LCD
Power Supply *
4 x AAA 1.5V Batteries / USB
Material
PC ABS / Cast Iron
Connectivity
USB 2.0 Cable (≤ 5 metre)
Bluetooth (≤30 metre) (Optional)
PC SYNC Software
Basic Edition
Professional Edition (Optional)
Operating Temperature
-10°C to +50°C (Calibrated)
14°F to 122°F (Calibrated)
Dimension (mm)
188 x 62 x 37
Nett Weight (Approx.)
1100 gram
User Self Calibration
Yes
Specifications are subject to change without notice.
*Alternative Device power can be obtained from External USB Power Source.
Note:
Product performance to specification are comply with accredited Calibration & Test Providers in USA, Japan, UK and
Germany to conform with NIST, JIS, UKAS & DIN under the International Laboratory Accreditation Cooperation (ILAC)
and American Association for Laboratory Accreditation (A2LA). For more information, please visit
“www.digipas.com”.
