Digi Connect and ConnectPort TS Family web interface Configuration through the web interface
Digi Connect Family and ConnectPort TS Family
66
n Enable RCI over Serial (DSR): This choice allows configure the Digi Connect device through
the serial port using the RCI protocol. See the RCI specification in the Digi Connect Integration
Kit for further details.
RCI over Serial uses the DSR (Data Set Ready) serial signal. Verify that the serial port is not
configured for autoconnect, modem emulation, or any other application which is dependent on
DSR state changes.
n Enable alternate pinout (altpin): Enables or disables the altpin option, which swaps DCD
with DSR so that you can use eight-wire RJ-45 cables with modems. By default, the altpin is
disabled.
TCP Settings
These TCP Settings are available only when you configure the current port with the Console
Management, Custom, or TCP Sockets profile.
n Send Socket ID: Include an optional identifier string with the data sent over the network.
The Socket ID can be 1 to 256 ASCII characters. Enter non-printable characters as
follows:
Character
Key
Sequence
backspace \b
formfeed \f
tab
\t
line feed
\n
return \r
backslash
\\
hexadecimal
values
\xhh
n Send data only under any of the following conditions: Enable if you need to specify the
conditions when the Digi device server will send the data read from the serial port to the TCP
destination.
