Digi SM-5300 Operation Manual

PLU Programming
–––––––––––––––––––––––––––––––––––––––––––
2.7 Barcode List
M o d e l S M - 5 3 00 O p e r a t i o n M a n u a l | 44
2.7.3 UPC Barcode Format
Barcode Type
Barcode Type
F1F2 CCCCC XCD XXXX CD
F2 CCCCC XCD XXXXX CD
F2 CCCCCC XCD XXXX CD
F1F2 CCC XXXXXXX CD
F1F2 CCCCC 0 XXXX CD
F1F2 CC XXXXXXXX CD
F1F2 CCCCCC XXXX CD
CCC WWWW PPPPP CD
F1F2 CCCCC XXXXX CD
F1F2 CCCCC PCD XXXX CD
F2 CCCCCC XXXXX CD
F1F2 CC NNN PPPPP CD
F2 CCCCC XXXXXX CD
F1F2 C NNNN PPPPP CD
F1F2 CCCCCCCCCC CD
F1F2 CC NNNN TTTT CD
F1F2 CCCC XXXXXX CD
F1F2 NNNN 0000000
F1F2 CCCCC CD
0F1F2 NNNN PCD PPPPP CD
F2 CC XXXX CD
F1F2 RR CCC XXXXX CD
NON BARCODE
F1F2 D CCCCCCCCCCCCC PPPPP WWWWW
F1X2 CCCCC XCD XXXX CD
F1F2 D CCCCCCCCCCCCC PPPPP QQ
F1X2 CCCCCC XXXX CD
F1F2 CCCC WWWWW LLLLLL
F1F2 CCCC XCD XXXXX CD
Note: F: Flag data, refer to SPEC141A003
C: Item Code number
X: Price or Quantity or Weight or Original Price or Weight/Quantity (depend to spec141A001)
CD: Check digit
N: Receipt Number
W’s – will be Weight for Weigh Item or Quantity for Non-Weigh Item
X’s – can be Quantity, Price, Weight or User Programmable depending on spec setting.
If spec is set to User Programmable, the last byte of EAN Data (7
th
byte) determines.
X’s definitions as follow:
P’s – will be Price for Weigh Item or Non-Weigh Item
LAST BYTE OF EAN DATA X’s
?0(HEX) PRICE
?1(HEX) WEIGHT
?2(HEX) QUANTITY
?3(HEX) ORIGINAL PRICE
CCC: PLU Code
RR: Clerk Code
CC: Scale Number, refer to spec141C001
NNNN: Serial Number
TTTT: Time (24 hours)
