digico SD8 - FOH and Monitors MADI Rig Setup

Page 7
FOH and Monitors Rig Using MADI.............................................
FOH & MONITORS
USING MADI ONLY
MONITORS
Audio Sync = MADI IN ON PORT 1
Uni-Directional Gain Tracking
FOH has control of the Analogue Gains
and Monitors can track this
OPTIONAL
LOCAL RAC
K
SHARED
STAGE RACK
OPTIONAL
LOCAL RACK
AUX
OUT
ONLY
PORT 1 IN
PORT 1
IN/OUT
PORT 2
PORT 2
MAIN
IN/OUT
MAIN
MAIN
FOH
A
udio Sync = MASTER
