Chapter 5: The Digi 002 Rack Front Panel 49
Monitor and Headphone Level Controls
Monitor Level Control Digi 002 Rack provides a
pair of Monitor Outputs that mirror its Main
Outputs (or outputs 1–2), which correspond to
outputs 1–2 in Pro Tools. This knob controls the
volume of those Monitor Outputs.
Headphone Level Control The Headphone Out-
put on Digi 002 Rack also mirrors outputs 1–2 in
Pro Tools, and is independent of the Monitor
Outputs. This knob controls the volume of the
independent Headphone Output.
Monitor Mute Switch This switch mutes the
Digi 002 Rack Monitor Outputs only, and has
no effect on the Main Outputs or the Head-
phone Output. Monitor Mute is automatically
engaged when you power up the Digi 002 Rack
unit.
Mono Output Switch This switch temporarily
combines the output signals 1 and 2 in both the
Monitor Outputs and the Headphone Output.
This is helpful for checking phase relationships
of stereo material. The Mono Output switch has
no effect on the Main Outputs.
Headphone Jack This jack accepts a standard
1/4-inch stereo headphone connector.
Status Indicators
Session Sample Rate Indicators
The Session Sample Rate LEDs indicate the sam-
ple rate of the current Pro Tools session.
Pro Tools Connection Status
Indicator
This status LED, marked “1394,” indicates that
communication has been established between
Digi 002 Rack and Pro Tools LE software
through FireWire.
MIDI Data Indicators
The MIDI Data LEDs indicate the presence of
MIDI data on the Digi 002 Rack MIDI In or
MIDI Out ports.
Digi 002 Rack Sample Rate LEDs
Connection Status LED
MIDI Data LEDs

SAMPLE RATE
44.1 48
88.2 96
1394

MIDI
IN OUT1
OUT2

