Copyright 2007 RTcom USA., Inc.
11
Output 5 to Input 1 and Input 2
EDID SW ASSIGN: save EDID data of
Byte Header ID Command
Number of
Output
Output Input 1 Input 2 Tail
ASCII ! 0 1 0 1 0 3 0 2 0 5 0 1 0 3 *
Hex 21h 30h 31h 30h 31h 30h 33h 30h 32h 30h 35h 30h 31h 30h 33h 2Ah
EDID SW ASSIGN SALVO: change all EDID data
Byte Header ID Command
Input1 of
Output
Input2 of
Output
Input3 of
Output
Input4 of
Output
Input5 of
Output
ASCII ! 0 1 0 1 0 4 0 2 0 3 0 4 0 5 0 6
Hex 21h 30h 31h h 31h h 32h 30h 33h 30h 34h 30h 35h 30h 36h 30 30h 34 30h
Byte
Input6 of
Output
Tail
ASCII 0 1 *
Hex 30h 31h 2Ah
ASSIG T STATU REQUE k t tatus of present input/output channels NMEN S ST: chec he s
Byte Header ID Command Tail
ASCII ! 0 1 0 1 1 0 *
Hex 21h 30h 31h 30h 31h 31h 30h 2Ah
RESET: reset the at m rix
Byte Header ID Command Tail
ASCII ! 0 1 0 1 2 0 *
Hex 21h 30h 31h 30h 31h 32h 30h 2Ah
FIRMWARE VERSION REQUEST: check the version of firmware
Byte Header ID Command Tail
ASCII ! 0 1 0 1 3 0 *
Hex 21h 30h 31h 30h 31h 33h 30h 2Ah
RS-232C ASSIGN: change RS-232C port selection (19200bps)
Byte Header ID Command Baud rate Data bit Stop bit Parity bit Tail
ASCII ! 0 1 0 1 4 0 0 4 0 0 0 0 0 0 *
Hex 21h 30h 31h 30h 31h 34h 30h 30h 34h 30h 30h 30h 30h 30h 30h 2Ah
Baud rate:
“ 00 ” : 1920 bps , “ 01 ” : 4800 bps , “ 02 ” : 9600 bps , “ 03 ” : 14400 bps , “ 04 ” : 19200 bps
, “ 08 ” : 76800 bps , “ 09 ” : 115200 bps
0”: 250000 bps
Data bit:
“ 00 ” : 8 bit , “ 01 ” : 5 bit , “ 02 ” : 6 bit , “ 03 ” : 7 bit
“ 05 ” : 28800 bps , “ 06 ” : 38400 bps , “ 07 ” : 57600 bps
“1
