4-3 Connector Pin Assignment
Power Input
Part No. Pin No. Description Remarks
1 VCC( DC12V)
2 VCC(DC12V)
3 GND
Power Jack(4P)
4 GND
RS-232C Input
Part No. Pin No. Description Remarks
1 Not used
2 Rx D
3 Tx D
4 Not used
5 GND
6 Not used
7 Not used
8 Not used
D-SUB 9 Pin Connector
9 Not used
LAN Input
Part No. Pin No. Description Remarks
1 Transmit data (+)
2 Transmit data (-)
3 Receive data(+)
4 Not used
5 Not used
6 Receive data(-)
7 Not used
RJ-45 8 Pin Connector
8 Not used
HDMI Input
Part No. Pin No. Description Remarks
1 TMDS DATA 2P
2 TMDS DATA 2 Shield
3 TMDS DATA 2M
4 TMDS DATA 1P
5 TMDS DATA 1 Shield
6 TMDS DATA 1M
7 TMDS DATA 0P
8 TMDS DATA 0 Shield
9 TMDS DATA 0M
10 TMDS Clock P
11 TMDS Clock Shield
12 TMDS Clock M
13 CEC
14 RESERVED
15 DDC Clock
16 DDC DATA
17 GND
18 +5v
HDMI 19 Pin Connector
19 Hot Plug Detect
