Ethernet Power Controller 7
17
Specications
Alert Beeper 73dBa at 12” Programmable
Applications Test equipment, industrial, datacenter
power control and reboot. Indoor use only.
Circuit Breakers Manual reset, 15A Thermal, UL Supplemental
Clock / RTC 15 year Li battery
Controls / Display Reset -to-factory-default switch, 2x16 Backlit LCD
w/ PowerSave, 5 button keypad, E-Stop
Enclosure Steel, double grounded. Vented 4 sides Fanless
Environmental Port RJ-12. Suitable for DHT/SHT series sensors
Ethernet Interface 10/100 autosensing, Static IP, TCP port selectable,
8 pin RJ-45 w/ internal FCC ltering
FCC Testing Part 15 FCC ID 2ACIUEPCR5
Humidity 8-80% RH Operating
Input Power Cord Fixed 14AWG with 5-15 plug standard 120VC only
Inlet and Outlet Rating UL, CSA 15A, 120VAC only
Input Frequency Power supply - DC-400Hz
Metering Accuracy +/- 2V, +/- .5A when calibrated at 50-60Hz only
Operating Temperature -30º to 170ºF, -34º to 77ºC
Options - Factory Input cord length and 120V plug style
Power Supply Rating 90-240V, AC/DC Autosensing
Password Transmission Encrypted, base 64 or HTTPS
Power Dissipation 5.3W Typ Max (all on, battery charging) <3 W idle
Power Fail Hold-Over 350ms minimum (all relays on)
Power-Up Modes Last used settings, all power on or o, sequential
on or run user-script ~30s after power-up
Relay Contact Spec 15-25A AC/DC, 1/2HP
Surge Protection Dual 3600WMetal Oxide Varistors
Size 3.5x5.5x19” 8.9x14x48cm 2-U
Weight (packed) Single unit 10.3lbs 4.7kg
WiFi Atheros 9331 2.4G 802.11n RP-SMA - FCC Note:
The EPCR5 may only be used with (1) the manu-
facturer supplied antenna (Gain: 2.0dBi), or (2) a
50 Ohm antenna of equal or lesser gain
