Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev D August 2017
Projector Overview
Front and rear views
1
Connection panel
2
Control panel
3
Front infrared window
4
Indicators
5
Lens mount
6
Voltage selector
7
Power switch and power connection
8
Air inlet
9
Air inlets
10
Rear infrared window
11
Air outlets
12
Adjustable feet
Notes
Front view
6 7
5
1
2
8
3
4
Rear view
12
11
9
10
