38
Nr. Functions Value
255 State of taximeter for light n. 3 ON: this is the state (or states) of the taximeter in which the light number 3 should be ON.
The allowed values are: 0 (none) - 32 (Hired) - 64 (Stopped) - 128 (ForHire).
Also combinations are allowed. In that case the values need to be summed together.
For example, to put ON light number 3 in Stopped and also in ForHire the value to program is: 64 + 128 = 192.
For Hire = 128
Stopped = 64
Hired = 32
None= 0
LIGHT N. 4
256 Enable light n. 4 ON in day-time? - Should it be possible for light number 4 to be ON during the day-time?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
257 Light n. 4 must flash? - If Yes light number 4 will flash. The allowed answer is either: 0 (No: no flash) or: 1 (Yes: flash). No / Yes
258 Light n. 4 must go ON in overspeed? - If Yes then light number 4 will go ON in case the actual velocity is higher than the velocity programmed in Q.200. The allowed
answer is either: 0 (No: OFF) or: 1 (Yes: ON).
No / Yes
259 Light n. 4 must go on below overspeed? No / Yes
from Q 260 to Q 262 available for any possible software extension
263 Light n. 4 ON in this tariff-block? - With Yes light number 4 will go ON in the corrisponding tariff-block. The allowed answer is either: 0 (No: OFF) or: 1 (Yes: ON). No / Yes
264 Block-number for light n. 4 ON: this is the number of the tariff-block where light number 4 should be ON. The allowed value goes from 0 (min) to 62 (max). 0 - 62
265 Prog-Date-number for light n. 4 ON: this is the number of the Prog-Date where light number 4 should be ON. The allowed value goes from 0 (min) to 8 (max). 0 - 8
266 State of taximeter for light n. 4 ON: this is the state (or states) of the taximeter in which the light number 4 should be ON.
The allowed values are: 0 (none) - 32 (Hired) - 64 (Stopped) - 128 (ForHire).
Also combinations are allowed. In that case the values need to be summed together.
For example, to put ON light number 4 in Stopped and also in ForHire the value to program is: 64 + 128 = 192.
ForHire= 128
Stopped= 64
Hired= 32
None= 0
VARIOUS FUNCTION
267 Must be Euro the default currency? - Establish default currency starting the trip No=Local currency Yes=Euro No / Yes
268 Disable visualization of clock on display? - Should the visualization of the clock on the (secondary) display be disabled?
The allowed answer is either: 0 (No: enabled) or: 1 (Yes: disabled).
No / Yes
269 Inhibit clock-time programming from panel? - Should the possibility to program the clock-time from the panel be inhibited?
The allowed answer is either: 0 (No: enabled) or: 1 (Yes: disabled).
No / Yes
270 Disable visualization of chronometer? - Should the visualization of the chronometer on the display be disabled?
The allowed answer is either: 0 (No: enabled) or: 1 (Yes: disabled).
No / Yes
271 In ForHire show text "F-HIRE" on display? - Should the text "F-HIRE" be shown on the primary display when in ForHire?
The allowed answer is either: 0 (No: show text) or: 1 (Yes: don't show text).
No / Yes
272 Distance is in yards ? (if not: metres) - The distance in Q.2 to Q.4 is in yards? If not then the distance is in metres.
The allowed answer is either: 0 (No: metres) or: 1 (Yes: yards).
0=metres
1=yard
273 Put ON the decimal point at pos. 2/3? Should the decimal point between the second and third position (from the right) be put ON? For example: 5.00.
The allowed answer is either: 0 (No: put OFF) or: 1 (Yes: put ON).
No / Yes
274 Put ON the decimal point at pos. 3/4? - Should the decimal point between the third and fourth position (from the right) be put ON? For example: 5.000.
The allowed answer is either: 0 (No: put OFF) or: 1 (Yes: put ON).
No / Yes
275 From Stopped back to Hired with key K2? - Should it be possible to go from Hired to Stopped pressing key K2?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
276 Chronometer shown as 9959? (if not: 9-59) - Should the time of the chronometer be shown as 9959 on the secondary display? If not, it will be shown as 9-59. So,
practically the dash is sacrificed for gaining another digit of the chronometer. The allowed answer is either: 0 (No: 9-59) or: 1 (Yes: 9959).
No / Yes
277 Chronometer shows minutes ? (if not: seconds) - Should the chronometer show minutes on the secondary display? If not, it will show seconds.
The allowed answer is either: 0 (No: seconds) or: 1 (Yes: minutes).
No / Yes
278
Show clock/year for 5 seconds with K3/K4? - If this question is enabled and key K3 is pressed then the clock will be shown on the secondary display and the date on the
main display for 5 seconds. With this question enabled and key K4 is pressed then the year will be shown on the main display for 5 seconds. This question is only
meaningfull if the visualization of the clock has been disabled with Q.268. The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
279
Disable manual programming of the Euro currency?
No / Yes
280
Disable the Euro conversion in Hired?
No / Yes
281
Disable the Euro conversion in Stopped?
No / Yes
282
Put off displays in ForHire after time of Q.283? – If yes then in ForHire the displays will be put off after the time established in Q.283.
See also Q.283. The allowed answer is either: 0 (No) or: 1 (Yes).
No / Yes
283 Stand-by time in Hired and Stopped: in Hired and Stopped this is the time after which the taximeter will go in stand-by. In stand-by the internal functions are all active but
the display is put OFF. The taximeter is 'woken-up' by either pressing any key or by the first pulse from the transducer. The time is given in minutes with an accuracy of 1
minute. The allowed value goes from 0 (min) to 255 (max).
0 - 255
minutes
284 Shut-down time in ForHire: in ForHire this is the time after which the taximeter will be shut-down. In shut-down all internal functions except the clock are disactivated and
also the display is put OFF. The taximeter is 'woken-up' by either pressing the OP key or by the first pulse from the transducer. Also see Q.192. If the answer is 0 the
taximeter doesn't switch-off automatically anymore. Is this case it can only be switched-off manually by pressing in For-Hire position K2 and K4 together. The time is given in
0 - 255
minutes
