40
Nr. Functions Value
309 Must the MES (Multi-Extra Charge System) be enabled? No / Yes
IR SENSOR FOR PASSENGER DETECTION
310 Distance to enable registration or ForHire: this is the distance that enables either the registration of the black fare with a passenger aboard in Stopped or the automatic
activation of Hired. See Q.313. The distance is given in metres with an accuracy of 0.1 meter. The allowed value goes from 0.0 (min) to 6553.5 (max). The digit indicating
multiples of 0.1 m (so at the right of the decimal point) will flash.
0 - 65535
311 IR-sensor for passenger-det. is present? - Is the Infra-Red-sensor for the detection of passengers present?
The allowed answer is either: 0 (No: not present) or: 1 (Yes: present).
No / Yes
312 IR-sensor contact is normally closed? - Is the Infra-Red-sensor contact a Normally Closed contact ? If not, then it is a Normally Open contact.
The allowed answer is either: 0 (No: normally open) or: 1 (Yes: normally closed).
0=open
1=closed
313 Black fare registr. or autom. in Hired? - After the distance programmed in Q.310 should be activated either: the registration in memory of the black fare with a
passenger aboard in Stopped or the automatic activation of Hired? The allowed answer is either: 0 (No: registration) or: 1 (Yes: pass to Hired).
0 = registration
1 = pass to Hired
314 Block taximeter if fare-memory is full? - Should the taximeter be blocked when the fare-memory is full?
The allowed answer is either: 0 (No: don't block) or: 1 (Yes: block).
No / Yes
315
The ForHire led flashes if IR-sensor is ON? - When the IR-sensor is activated should the ForHire led flash?
The allowed answer is either: 0 (No: don't flash) or: 1 (Yes: flash).
No / Yes
from Q 316 / Available for any possible software extension / to Q 318
STATISTICAL MEMORY BLOCK N.1
319 Inhibit visualization memory-block n. 1? - Should it be impossible to visualize memory-block number 1? See also Q.320.
The allowed answer is either: 0 (No: visualize) or: 1 (Yes: inhibit).
No / Yes
320 Enable visualization MB1 with password? - If the visualization of memory-block number 1 has been inhibited (see Q.319) should it be possible to undo this with the
password? The allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
321 Inhibit printing memory-block n. 1? - Should it be impossible to print memory-block number 1? See also Q.322.
The allowed answer is either: 0 (No: print) or: 1 (Yes: inhibit).
No / Yes
322 Enable printing MB1 with password? - If the printing of memory-block number 1 has been inhibited (see Q.321) should it be possible to undo this with the password? The
allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
323 Inhibit reset of memory-block n. 1? - Should it be impossible to reset memory-block number 1 from panel? See also Q.324.
The allowed answer is either: 0 (No: reset from panel) or: 1 (Yes: inhibit).
No / Yes
324 Enable reset of MB1 with password? - If the reset from panel of memory-block number 1 has been inhibited (see Q.323) should it be possible to undo this with the
password? The allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
325 Inhibit access to stat. Memory n. 1? - Should it be impossible to have access to the reading-procedure of the statistics-memory number 1?
The allowed answer is either: 0 (No: access) or: 1 (Yes: no access).
No / Yes
ACCESS TO TARIFF PROGRAMMING
326 Programming only with the memory-key? - Should programming only be possible with the memory-key? If not, then programming is also possible step by step. The
allowed answer is either: 0 (No: also step by step) or: 1 (Yes: only memory-key).
No / Yes
STATISTICAL MEMORY BLOCK N. 2
327 Inhibit visualization memory-block n. 2? - Should it be impossible to visualize memory-block number 2? See also Q.328.
The allowed answer is either: 0 (No: visualize) or: 1 (Yes: inhibit).
No / Yes
328 Enable visualization MB2 with password? - If the visualization of memory-block number 2 has been inhibited (see Q.327) should it be possible to undo this with the
password? The allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
329 Inhibit printing memory-block n. 2? - Should it be impossible to print memory-block number 2? See also Q.330.
The allowed answer is either: 0 (No: print) or: 1 (Yes: inhibit).
No / Yes
330 Enable printing MB2 with password ? - If the printing of memory-block number 2 has been inhibited (see Q.329) should it be possible to undo this with the password? The
allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
331 Inhibit reset of memory-block n. 2 ? - Should it be impossible to reset memory-block number 2 from panel?
See also Q.332. The allowed answer is either: 0 (No: reset from panel) or: 1 (Yes: inhibit).
No / Yes
332 Enable reset of MB2 with password? - If the reset from panel of memory-block number 2 has been inhibited (see Q.331) should it be possible to undo this with the
password? The allowed answer is either: 0 (No: keep inhibited) or: 1 (Yes: enable with password).
No / Yes
333
Enable auto-advance of stat. memory? - Should the number of the statistics-memory advance automatically (instead of manually) during the reading-procedure ? The
allowed answer is either: 0 (No: manually) or: 1 (Yes: automatically).
No / Yes
334 Divide income of mem.-block n. 2 by 100? - Should the income of memory-block n. 2 be divided by 100?
The allowed answer is either: 0 (No: don't divide) or: 1 (Yes: divide).
No / Yes
PRE-PAID CARD
335 Hide on the Ticket the message "Thanks"? No / Yes
336 Enable on the Ticket the 3 lines footer? No / Yes
