42
Nr. Functions Value
See also Q.383 to Q.385 and Q.387. The allowed answer is either: 0 (No: Digitax protocol) or: 1 (Yes: custom protocol). 1= Custom
387
Enable LogIn/LogOut commands? - The questions Q.387 and Q.389 are very much related to each other. They deal with command execution in relation with th status of
being logged-in or logged-out. Their relationship is as follows:
No / Yes
Q.387 Logged-In Q.389 cmd=LogIn Action
No X X - Normal operation without limits.
Yes No No - Execute command without answer.
Yes No Yes No Abort Command.
Yes No Yes Yes Change status to Logged-in.
Yes Yes X - Normal operation without limits.
The varies items in the tabel have the following meaning:
Logged-In : is the status Logged-In? If No then the status is Logged-Out. cmd=LogIn - is the command a Log-In command?
X : This can be either Yes or No; it has no importance. - : this means that it doesn't apply.
The allowed answer is either: 0 (No: Enabled) or: 1 (Yes: Disabled).
Q 388 / Available for any possible software extension /
389
During LogOut mode reject commands? - The questions Q.387 and Q.389 are very much related to each other.
They deal with command execution in relation with the status of being logged-in or logged-out. Their relationship is as follows:
No / Yes
Q.387 Logged-In Q.389 cmd=LogIn Action
No X X - Normal operation without limits.
Yes No No - Execute command without answer.
Yes No Yes No Abort Command.
Yes No Yes Yes Change status to Logged-in.
Yes Yes X - Normal operation without limits.
The varies items in the tabel have the following meaning:
Logged-In : is the status Logged-
In ?
if No then the status is Logged-
Out.
cmd=LogIn : is the command a
Log-In command ?
X : this can be either Yes or
No; it has no importance.
- : this means that it doesn't apply.
The allowed answer is either: 0 (No: abort command) or: 1 (Yes: execute command (login only).
390 Enable Credit Card authorization numeric field? No / Yes
391 Baudrate for COM 1: what is the baudrate (transmission-speed) of COM 1? The baudrate is given in baud with an accuracy of 1 baud.
The allowed value goes from 0 (min) to 65535 (max).
0 - 65535
baud
392 Maximum packet length for COM 1: what is the maximum length of a data-packet of COM 1? The packet length is given in byte with an accuracy of 1 byte. The allowed
value goes from 1 (min) to 512 (max).
0 - 512
393 Baudrate for COM 2: what is the baudrate (transmission-speed) of COM 2? The baudrate is given in baud with an accuracy of 1 baud.
The allowed value goes from 0 (min) to 65535 (max).
0 - 65535
baud
394 Maximum packet length for COM 2: what is the maximum length of a data-packet of COM 2? The packet length is given in byte with an accuracy of 1 byte. The allowed
value goes from 1 (min) to 512 (max).
1 - 512
395 First cost threshold for authorization: this is the first amount above which authorization is requested for acceptance of the payment of the fare with a credit-card. The cost
is given in the local currency with an accuracy of 1. The allowed value goes from 0 (min) to 1000000 (max).
1 - 1000000
396 Second cost threshold for authorization: this is the second amount above which authorization is requested for acceptance of the payment of the fare with a credit-card.
The cost is given in the local currency with an accuracy of 1. The allowed value goes from 0 (min) to 1000000 (max).
0 - 1000000
397 Third cost threshold for authorization: this is the third amount above which authorization is requested for acceptance of the payment of the fare with a credit-card. The
cost is given in the local currency with an accuracy of 1. The allowed value goes from 0 (min) to 1000000 (max).
0 - 1000000
398 Time-out for authorization of payment: this is the waiting-time during which authorization is requested for acceptance of the payment of the fare with a credit-card. If the
authorization is not obtained within this time then the request is considered denied. The waiting-time is given in seconds with an accuracy of 0.1 second. The allowed value
goes from 0.0 (min) to 6553.5 (max). The digit indicating multiples of 0.1 sec. (so at the right of the decimal point) will flash.
0 - 65535
seconds
399
Time-Out keyboard locked: this is the time after which the keyboard gets unlocked (activated) automatically if WD-commands are not received anymore. As long as this
time has not passed the keyboard remains locked (not active).
This is valid for a time-out value of 1 or higher. A time-out value of 0 is a special case. In this case there is no time-out and the keyboard can only be unlocked by means of
an unlock-command (LM-command). See also paragraphs 2.1.2 (LM-command) and 2.1.22 (WD-command) of the commtax2 manual. The time is given in seconds with an
accuracy of 1 sec. The allowed value goes from 0 (min) to 255 (max).
0-255
400
Time out from trip start to accept forfait price.
0 - 65535
from Q 401 / Available for any possible software extension / to Q 402
403
Key bitmap enabled while the keyboard is blocked by overspeed
No / Yes
404
Tariff number to which are destinated all statistical memories calculated by the current block
0-6
405
Min. distance (in meters) which allows the trip to be saved (if less, tripp will be not considered)
0-255
406
Speed to block the keyboard of the taximeter: this is the speed above which the keyboard of the taximeter gets locked. As soon as the speed becomes less than this
threshold the keyboard gets unlocked again. Normally the value programmed here is a low speed like for example 10 Km/h. The speed is given in Km/h with an accuracy of 1
Km/h. The allowed value goes from 0 (min) to 255 (max). The value 0 is a special case. It means: disabled.
0-255
407
Speed to block the counting of the tariff: this is the speed above which the taximeter stops counting the tariff. As soon as the speed becomes less than this threshold the
taximeter continues counting the tariff again. Normally the value programmed here is a high speed like for example 140 Km/h. The speed is given in Km/h with an accuracy of
1 Km/h. The allowed value goes from 0 (min) to 255 (max). The value 0 is a special case. It means: disabled.
0-255
408 Block number if from Stopped back to Hired: this is the number of the block that will be used when passing from Stopped back to Hired.
The allowed value goes from 0 (min) to 62 (max).
0 – 62
409 Block number if from Stopped to ForHire: this is the number of the block that will be used when passing from Stopped to ForHire.
The allowed value goes from 0 (min) to 62 (max).
0 - 62
