Digitus DA-90433 - Operating Unit; Product Outline; Product Specification

9
Port for adapter
cable
Port for
Headset
Port for cable
connected
to the lifting
column
5. Operating unit
Product Outline
LED Display
Product Specification
Button introduction:
There are seven buttons that "▲", "▼", "1", "2", " ", " ", "M"
(1) "▲": Adjust the desk upwards
(2) "▼": Adjust the desk downwards
(3) "1": Position 1, first height position saved by the user
(4) "2": Position 2, second height position saved by the user
(5) " ": the display shows “3”, which means the position of the standing
height the user saved.
(6) " ": the display shows “4”, which means the position of the standing
height the user saved.
(7) "M": Height saving button, for height memory function;
Child lock: for security
