Digitus DN-13003-2 User Manual

2
Before you start, you should prepare the following items:
 Windows 2000/XP/2003/Vista/7/8/10 computer with print server setup CD
 One Printer(non-GDI/CAPT)
 One Printer cable
 One 802.11b/g/n Access Point (optional)
Wired Network with Print Server:
Printer
Print Server
Computer Computer Computer
HUB
Factory Default Settings:
 Password:
 IP Address: 192.168.0.10
 Subnet Mask: 255.255.255.0
Hardware Installation:
1. Turn off the printer’s power.
2. Connect the print server to your printer with the supplied printer cable.
3. Turn the printer’s power on.
4. Plug the AC power adapter into the power connector on the print server.
5. Wait 40 seconds as part of the print server’s Power On Self Test (POST).

Digitus DN-13003-2 Specifications

General

Internal	No
DHCP client	Yes
Product color	White
Country of origin	Taiwan
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	-
Ethernet LAN (RJ-45) ports	1
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Network connection type	Ethernet LAN
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Supported network protocols	TCP/IP, IPX/SPX, NetBEUI, AppleTalk,
Package type	Box
Package depth	68 mm
Package width	230 mm
Package height	153 mm
Package volume	2392.92 cm³
Package weight	60 g
Master (outer) case width	366 mm
Master (outer) case height	492 mm
Master (outer) case length	340 mm
Master (outer) case volume	61224.5 cm³
Master (outer) case weight	9500 g
Quantity per master (outer) case	20 pc(s)
