SPECIFICATION
Capacity VA 600VA 800VA
Input
Voltage 220VAC/230VAC/240VAC
Voltage Range 162-290VAC
Output
Voltage
Regulation
(Batt. Mode)
+/- 10%
Frequency 50Hz or 60Hz
Frequency
Regulation
(Batt. Mode)
+/- 1Hz
Output
Waveform
Simulated Since
Wave
Battery
Battery Type
12V/7.0
AHx1
12V/9.0
AHx1
Recharge Time
6-8 hours to 90% after
complete discharge
Transfer
Time
Typical 2-6 ms
USB Charger Typical 5.0V/2.0A Max.
Indicator
AC Mode Green LED lighting
Battery Mode Yellow LED lighting
Fault Mode Red LED lighting
Audible
alarm
Backup Mode Sounding every 10 seconds
Low Battery Sounding every 1 second
Overload Sounding every 0.5 second
Fault Continuously Sounding
Protection Full Protection
Discharge, overcharge,
and overload protection
Physical
Dimension (mm),
L x W x H
293 x 202 x 93
Weight 4.5 kg 5.2 kg
Environment
Operating
Environment
0-90% RH @ 0-40°C
(non-condensing)
Noise Level Less than 40dB
