Digitus DN-651126 User Manual

3
Hardware Description
Upper Panel
The upper panel has a standard 3-Pin industrial power input terminal
for DC power input. Also Ethernet Ports and LED indicators are located
on the panel.
DN-651126
DN-651127
LED indicator
LED
Color
Function
Power
Red
Off: No Power supply
Light: Indicates the switch has power
Act
Green
Off: No device is connected to the corresponding port
Light: Indicates the link through that port is
successfully established at 10/100/1000Mbps
Blink: Indicates that the Switch is actively sending or
receiving data over that port

Digitus DN-651126 Specifications

General

Brand	Digitus
Model	DN-651126
Category	Switch
Language	English
