9
7.3 grounding
Fix the grounding wire to the grounding screw above
the switch, and ensure good reliable connection of
the grounding system.
7.4 Power Connection
Insert the power cord into the specified position of the 6-core terminal,
and insert the terminal into the standard power supply inlet (P+1 and
P-1 input corresponding to the first power supply P1, and P+2 and P-2
input corresponding to the second power supply P2). The available
voltage standard of the power supply is supported from 12VDC to
52VDC
8. Packages
