Digitus DN-652120 User Manual

8
Pin No.
MDI signal
MDI-X-signal
1
TX+
RX+
2
TX-
RX-
3
RX+
TX+
6
RX-
TX-
4, 5, 7, 8
-
-
Note: "Tx ±" refers to sent data ±, "Rx ±" refers to received
data ±, and "-" refers to unused data.
7. LED Indicator
LED
indicator
Status Definition
Power
Red LED on
Power supplying in normal
Red LED off
Power supply abnormal or
no powering
RJ45
indicator
Yellow LED on
Network connection in
normal
Yellow LED
flashing
Link communication in
normal
Green LED on
PoE feeding in normal
Yellow/Green
LED off
No connection at port
