Digium, Inc. Page 23

Chapter 2: Card Installation

Figure 3: AEX410 Card with Four Single Modules

Single

Modules

1

2

3

4

1

2

3

4

Power

Supply

Connection

VPMADT032 Echo

Cancellation Module
