Digium, Inc. Page 26
Chapter 2: Card Installation
FXS and FXO Connection
The Analog 410 Series cards provide four RJ11 connectors for access to
the FXS and/or FXO modules installed in the available slots. The diagram
in Table A-1 on page 56 provides the pinout for this connector.
Slot Compatibility
Check the type of card you received to be sure it is compatible with your
PCI slot. To determine which slot you have, identify it by comparing it to
those shown in Figure 4 on page 27.
Slot Number:
0: AGP Pro Slot
1: 64-bit 5.0 volt PCI Slot
2: 64-bit 3.3 volt PCI Slot
3: 32-bit 5.0 volt PCI Slot
4: PCI Express Slot
Caution.
Only qualified service personnel should continue with
hardware installation and configuration of the Analog 410
Series card. Users should not attempt to perform these
functions themselves.
