Digium, Inc. Page 57
Appendix B
Specifications
This appendix provides specifications, required environmental
conditions, and maximum power consumption for the Analog 410
Series cards.
Physical (All Cards).
Size: 6.48” × 4.2” × 0.68” (16.46 x 10.67 x 1.72 cm)
PCB size, does not include the PCI bracket.
Check your model carefully to be sure it will accept
this PCI card.
Weight: 3.5 oz (99.22 gm) with no modules loaded
Each single module adds 0.4 oz (11.34 gm)
VPMADT032 adds 0.63 oz (17.86 gm)
Interfaces.
Local Loop Access: Industry standard 6-pin RJ-11.
(TDM410) - PCI Bus: 3.3V or 5V bus slot, half-length full-height PCI
card, 33MHz minimum bus speed, compliant with PCI 2.2 or greater.
Additional Power: four-pin 12V connector for FXS power supply
(required only if FXS modules are installed)
(AEX410) - PCI-E X1, compliant with PCI-E X1 1.0 or greater.
