Advanced Force Gauge User’s Manual
29
If the current % offset is as shown below, follow the
appropriate action.
Lower Value Action
-4.9% to 4.9% Normal offset provided
upper and lower values are
within 5% of each other
-5.0% to -9.9% Contact Quantrol distributor
5% to 9.97% for recalibration
-10% and greater Contact Quantrol distributor
10% and greater for loadcell replacement
These values are given as an indicator only – the
need for calibration/repair may vary according to the
individual characteristics of the load cell.
Press and hold ESC until you return to page 2 of main
menu.
A constant of multiplication can be applied to the load
values in the main display. This is useful for applica-
tions where you wish to convert the load reading into
a non-standard unit of measurement e.g. for co-
efficient of friction tests.
Press ENTER to select xCONSTANT. Press UP or
DOWN to adjust the constant of multiplication. Press
ENTER to confirm.
The contrast of the display may be increased and
decreased in this menu.
From page 2 of main menu press UP or DOWN keys
to position the arrow key on CONTRAST. Press
ENTER to select CONTRAST menu and 1.234 will be
displayed. Press UP or DOWN to adjust the contrast
of the display and ENTER to confirm the setting. You
will now return to page 2 of the main menu.
x/CONSTANT
CONTRAST
