7
Fig. 2
‘D’‘B’
160
mm
(min)
‘A’
‘C’
75mm (min)
‘A’
‘B’
150
mm
(min)
150mm
(min)
Fig. 1a
305mm
(min)
75mm
Shelf
Fig. 1b
Minimum front
clearance
MODEL Watts A B C D
B075E 750 570mm 659mm 405mm 507mm
C100E 1000 840mm 659mm 675mm 507mm
D150E 1500 1105mm 659mm 940mm 507mm
E200E 2000 1373mm 659mm 1208mm 507mm
