6
Select a suitable position on a wall, near to a mains power outlet. The radiator should not be
mounted closer than 75mm from the oor - see Fig. 3 (to enable cleaning), or adjacent side
walls. Ensure at least 305mm clear space between the radiator and any overhanging shelf - see
Fig 6. It should not be mounted closer than 1 metre from the ceiling.
STEP 1: Check that you have all the necessary components:
(a) 2 x Bottom Wall brackets
(b) 2 x Top Wall Brackets
(c) 2 x Radiator Securing Brackets
(d) 2 x Screws Self-tapping.
STEP 2: Using a straight edge, draw a horizontal line (see ‘Y’ in Fig. 3) for the bottom brackets
at the required mounting height from the oor.
THE RADIATOR MUST ONLY BE WALL MOUNTED USING THE KIT SUPPLIED.
WARNING:
This product is heavy and care should be taken in installation
NOTE:
The bottom of the radiator must not be less than 75mm from the oor.
To achieve this, the top edge of the bottom brackets must be at least
160mm from the oor – see Fig. 2. On this line, mark off the xing centres
according to model – see ‘C’ in the table in Fig. 2 and Fig. 3.
Place the bottom brackets centrally over these centres with the top row of holes on the line,
and mark the xing hole positions – see Fig. 3.
STEP 3: Drill the holes and t wall plugs. Screw the bottom brackets in position
– see Fig. 3.
STEP 4: Measure dimension D in Fig. 2 according to model, from the top of the bottom brackets
and draw a horizontal line. Mark off the xing centres for the top brackets in line with
the bottom brackets. Place each top bracket on the line and mark the xing holes – see
Fig. 4. Drill and plug the wall and x the top brackets in place.
STEP 5: Place the radiator on the bottom brackets, then t each securing bracket to the top of
the radiator and secure it with the self-tapping screw provided – see Fig. 5.
Check that the radiator is securely xed to the wall.
Wall Mounting Instructions
IMPORTANT:
For safe clearances from shelf/obstacle - see Fig. 6
