Maintenance
the opposite end from the support
bracket (Figure 10).
Upper Light Bulb Requirements
Quantity of two (2) clear
chandelier or candelabra bulbs
15 Watt rating.
Do not exceed 15 Watts per
bulb.
To access the upper light bulb
area:
① Carefully remove the front
some of the glass media may fall
out of the tray (Figure 9).
②
upper left and upper right corners
③ Remove the upper light cover
for each bulb (two (2) Philips
screws each).
④
clockwise.
⑤ Insert new bulb(s).
⑥
⑦ Replace glass assembly.
Figure 10
Exploded view to show detail
Flicker Rod
Flicker
Motor
⑤
(see Figure 10).
⑥
clockwise.
⑦ Insert new bulb(s).
⑧
motor shaft and replace opposite
support bracket.
⑨Replace media tray back into
⑩ Gently pour and evenly
spread the glass media.
⑪ Replace glass assembly.
