• This appliance is for outdoor use only.
• This appliance must be securely mounted on a wall.
• This appliance shall only be used in an above ground open-air situation with natural ventilation, without
stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural
convection.
• Any enclosure in which the appliance is used shall comply with one of the following:
1. An enclosure with walls on all sides, but at least one permanent opening at ground level.
2. Within a partial enclosure that includes an overhead cover and no more than two walls.
3. Within a partial enclosure that includes an overhead cover and more that two walls, the following shall
apply:
- At least 25% of the total wall area is completely open.
- At least 30% of the remaining wall area is open and unrestricted.
- In the case of balconies, at least 20% of the total wall area shall be and remain open and unrestricted.
Figure 1 shows examples of outdoor areas. These same principles apply to any other shaped area.
IMPORTANT INSTRUCTIONS
Figure1
Figure 1a - Outdoor Area Example 1
Walls on all sides, one permanent opening
Figure 1b - Outdoor Area Example 2
Partial enclosure with overhead cover
Figure 1c - Outdoor Area Example 3
Partial enclosure with overhead cover
Figure 1d - Outdoor Area Example 4
Partial enclosure with overhead cover, more than two walls
Figure 1e - Outdoor Area Example 5
Partial enclosure with overhead cover, more than two walls
Open side
at least 25%
of total wall
area
Both ends open
Open side
at least 25%
of total wall
area
30% or more in total of
the remaining wall area
is open and unrestricted
30% or more in total of
the remaining wall area
is open and unrestricted
