Dimplex DHW 300+ - Advanced functions

EN-9 451905.66.01 · FD 9505 www.dimplex.de
English
DHW 300 - DHW 300+
1st drawdown
Start time 00:00 ... 23:59 Sets the start time for lower
End time 00:00 ... 23:59 Sets the end time for lower
Days
Mo ... Su
Mo - Fr
Sa - Su
Mo - Su
Sets the weekday / block of days on which the lowering
of the domestic hot water temperature should be acti-
vated
2nd drawdown
Start time 00:00 ... 23:59 Sets the start time for lower
End time 00:00 ... 23:59 Sets the end time for lower
Days
Mo ... Su
Mo - Fr
Sa - Su
Mo - Su
Sets the weekday / block of days on which the lower
should be activated
(only visible for devices with additional heat exchanger)
2nd heating device
Heater sel.
Off
2nd
Sol
Choice of additional heat source
Off: (no add. heat source)
2nd: 2nd heat generator, e.g. oil, gas or wood boiler
Sol: Thermal solar energy system
Bivalent temp.
-8 °C ... 10 °C ... 15 °C
Limit temperature for the 2nd heat generator. The heat
pump is blocked below this temperature
(The setting of the 2nd heat generator or solar energy system only takes effect if the menu has been exited completely with the Esc key
after the setting is made. When the menu is called up again, the following menus appear depending on the setting)
(when 2nd is selected:)
Heater sel.
Off
2nd
Sol
Choice of additional heat source
Off: (no add. heat source)
2nd: 2nd heat generator, e.g. oil, gas or wood boiler
Sol: Thermal solar energy system
Bivalent temp.
-8 °C ... 10 °C ... 15 °C
Limit temperature for the 2nd heat generator. The heat
pump is blocked below this temperature
(when Sol is selected:
s. Solar menu block)
Photovoltaics
Photov. Active
Yes
No
Activates the photovoltaic function.
Set point PV
35 °C ... 45 °C ... 60 °C
Entry of the domestic hot water setpoint, which is active
when photovoltaic inlet is wired. The increased setpoint
is also active if the air intake temperature does not allow
the heat pump to operate. In this case, the request is
processed with the electric heating element or, where
present, the 2nd heat generator.
information
Operation state
upper heat accu. Display of the cylinder temperature top
lower heat accu. Display of the cylinder temperature bottom
air intake Display of the air temperature
collector temp. Display of the collector temperature (only on models
with additional heat exchanger and Sol selected as 2nd
heat generator)
act. set point Displays the current domestic hot water setpoint
ventilation Shows the switching status of the fan
compressor Shows the switching status of the compressor
heater Shows the switching status of the heating element
power Shows the calculated power consumption of the device
operating mode Displays the current operating mode
Menu block Menu item Parameter Value Description
