DHW 300 - DHW 300+
7.2 Menu structure
Parameter change: The menu is accessed using the "Menu"
key. In this menu, changes can be made to parameters. The de-
sired menu item is selected with the arrow keys "UP" "DOWN".
The submenu is accessed using the "OK" key.
In this submenu, the parameter that is to be changed can be se-
lected (also using the arrow keys). The "OK" key is used to se-
lect the marked value, which can then be changed via the arrow
keys. The entry is completed by pressing the "OK" key again.
Menu block Menu item Parameter Value Description
Settings
System time
00:00 Time setting (24 hour time display)
System date
DD:MM:YYYY Date setting (Day:Month:Year)
Language
German
English
Language selection
Sound
On
Off
Setting key tone on / off
Backlight
0 % ... 50 % ...100 % Setting display backlight
Warm water
Set point temp.
25 °C ... 45 °C ... 85 °C Sets the desired domestic hot water set temperature
Setback tempera
15 °C ... 25 °C ... 40 °C
Sets the minimum hot water temperature, which should
also not be undershot for the duration of a programmed
shut-off time.
Hysteresis
2 K ... 3K ... 10 K Sets the switching hysteresis
(only visible for devices with additional heat exchanger and Sol selection under the menu block 2nd heat generator
Solar
Heater sel.
Off
2nd
Sol
Choice of additional heat source
Off: (no add. heat source)
2nd: 2nd heat generator, e.g. oil, gas or wood boiler
Sol: Thermal solar energy system
Switch on differenc
6 K ... 8K ... 10 K
Sets the temperature difference between the collector
and cylinder temperature at which the solar pump
should be switched on
Switch off differenc
2 K ... 4K ... 6 K
Sets the temperature difference between the collector
and cylinder temperature at which the solar pump
should be switched off
Max. storage tem
60 °C ... 65 °C ... 85 °C
Sets the maximum cylinder temperature that is permis-
sible when solar gain is available
Max. collector tem
125 °C ... 130 °C ... 135 °C
Sets the maximum permissible temperature on the col-
lector
Time programs
Therm. disinfection
Start time
00:00 ... 23:59
Sets the start time for thermal disinfection (24 hour time
display)
Days
Mo ... Su
Sets the day on which thermal disinfection should be
activated
Sollwert
60 °C ... 65 °C ... 85 °C Sets the set temperature for thermal disinfection.
