B. Heater ON/OFF Switch
TheHeaterON/OFFSwitchsuppliespowertotheheaterfanandthe
heaterelement.
C. Heater Thermostat Control
Toadjustthetemperaturetoyourindividualrequirements,turnthe
thermostatcontrolclockwiseallthewaytoturnontheheater.When
theroomreachedthedesiredtemperature,turnthethermostatknob
counterclockwiseuntilyouhearaclick.Leaveinthispositionto
maintaintheroomtemperatureatthissetting.Foradditionalheat,turn
clockwiseuntilyouheartheclickagainandtheheaterwillturnon.
Toturntheheateroff,switchtheHeaterON/OFFSwitchtotheOFF
position.
!
NOTE: WhentheheaterisswitchedON,theheaterfanwill
operate.Theheaterelementmayormaynotbeon,dependingon
thethermostatcontrolsetting(see“HeaterThermostatControl”).
Resetting The Temperature Cutoff Switch
Shouldtheheateroverheat,anautomaticcutoutwillturntheheater
offanditwillnotcomebackonwithoutbeingreset.Itcanberesetby
switchingtheMainON/OFFSwitchtoOFFandwaitingve(5)minutes
beforeswitchingtheunitbackon.
Figure 1
A
B
C
