Dimplex ECR15 User Manual

Fitting The Castors
A
B
WARNING The radiator must only be operated with the wheels and castors tted
and in an upright position. The castors must be tted to the control panel and on the
bracket between the last and second last n on the opposite end, as shown in Fig.1.
1. To t the castors, turn the radiator upside down on a carpet or other soft surface
to avoid damage Warning: The radiator is heavy – ensure that it is supported to
prevent it from toppling. Ask a second person to help with this if necessary.
2. To t the castors, position the castor plates (A) in position and secure using the
wing bolts provided (B). There are guides to ensure the correct positioning and
orientation of the caster plate.
3. Return the radiator to the correct orientation so it rests on the castors. The
product is now ready for use.
Fig. 1
6

Dimplex ECR15 Specifications

General

Type	Oil-free radiator
Cord length	1.8 m
Certification	BEAB
Frost free mode	Yes
Heating element type	Aluminum
Suitable for	Indoor
Product color	White
Placement options	Floor
Heating power	1500 W
Heating power (min)	500 W
Handheld remote control	No
Export Control Classification Number (ECCN)	-
Commodity Classification Automated Tracking System (CCATS)	851629500

Weight and Dimensions

Depth	281 mm
Width	389 mm
Height	629 mm
Weight	7780 g
Package depth	166 mm
Package width	490 mm
Package height	648 mm
Package weight	8960 g
