www.dimplex.de 452162.66.04 · FD 9606 EN-19
English
LAW 6IMR - LAW 14ITR
13 Device information
1 Type and order code
LAW 6IMR LAW 9IMR LAW 14IMR LAW 14ITR
2Design
Heat source Air Air Air Air
2.1 Model Split reversible Split reversible Split reversible Split reversible
2.2 Controller
WPM Econ5Plus
integrated
WPM Econ5Plus
integrated
WPM Econ5Plus
integrated
WPM Econ5Plus
integrated
2.3 Thermal energy metering No No No No
2.4 Installation location Indoors / outdoors Indoors / outdoors Indoors / outdoors Indoors / outdoors
2.5 Performance level Variable Variable Variable Variable
3 Operating limits
3.1 Heating water flow / return °C up to 55 / from 20 up to 55 / from 20 up to 55 / from 20 up to 55 / from 20
3.2 Cooling water flow °C 7 to 25 7 to 25 7 to 25 7 to 25
3.3 Air (heating) °C -20 to +30 -20 to +30 -20 to +30 -20 to +30
3.4 Air (cooling) °C +10 to +43 +10 to +43 +10 to +43 +10 to +43
4 Flow / sound
4.1 Heating water flow / internal pressure differential
in accordance with EN 14511 m³/h / Pa 1,6 / 20000 1,6 / 20000 2,4 / 30400 2,4 / 30400
free compression Pa 38800 38800 29600 29600
Minimum heating water flow
internal pressure differential m³/h
0,75 / 8500 0,75 / 8500 0,9 / 10000 0,9 / 10000
free compression Pa 68500 68500 77300 77300
4.2 Noise-power level in accordance
with EN 12102 outdoors
1
dB(A)
63 63 68 67
4.3 Sound pressure level in 10 m distance outdoors
1
2
dB(A)
32 32 37 36
4.4 Noise-power level in accordance
with EN 12102 indoors dB(A)
42 42 42 42
4.5 Sound pressure level in 1 m distance indoors dB(A) 35 35 35 35
4.6 Air flow m³/h / Pa 3600 3600 7200 7200
5 Dimensions, weight and filling quantities
5.1 Device dimensions
3
internal H x W x D mm
external H x W x D mm
1920 x 740 x 950
834 x 950 x 330
1920 x 740 x 950
834 x 950 x 330
1920 x 740 x 950
1380 x 950 x 330
1920 x 740 x 950
1380 x 950 x 330
5.2 Weight of the transportable unit(s)
incl. packaging internal / external kg
215 / 69 215 / 69 222 / 94 222 / 116
5.3 Device connections for heating inches G 1 1/4" G 1 1/4" G 1 1/4" G 1 1/4"
5.4 Refrigerant; total filling weight type/kg R410A / 1.9 R410A / 1.9 R410A / 2.38 R410A / 2.98
5.5 Lubricant; total filling quantity type/litres
Polyvinyl ether
(PVE) / 0.9
Polyvinyl ether
(PVE) / 0.9
Polyvinyl ether
(PVE) / 1.3
Polyvinyl ether
(PVE) / 1.3
5.6 Volume of heating water in the outdoor component Litres 0000
5.7 Buffer tank
Nominal volume in litres 100 100 100 100
Permissible operating temperature °C 85 85 85 85
Max. operating overpressure bar 3,03,03,03,0
Electrical pipe heater kW
2, 4 or 6
4
2, 4 or 6
4
2, 4 or 6
4
2, 4 or 6
4
Immersion heater (optional) kW up to 6 up to 6 up to 6 up to 6
5.8 Domestic hot water cylinder
Usable capacity in litres 277 277 277 277
Heat exchanger area m² 3,15 3,15 3,15 3,15
Permissible operating temperature °C 95 95 95 95
Max. operating pressure bar 10,0 10,0 10,0 10,0
Immersion heater kW 1,51,51,51,5
5.9 Start-to-leak pressure, safety valve bar 2,5 2,5 2,5 2,5
6 Electrical connection
6.1 Supply voltage / fuse protection Compressor
1~/N/PE 230 V
(50Hz) / C25A
1~/N/PE 230 V
(50Hz) / C25A
1~/N/PE 230 V
(50Hz) / C40A
Heating cartridge
1~/N/PE 230 V
(50Hz) / C35A
1~/N/PE 230 V
(50Hz) / C35A
1~/N/PE 230 V
(50Hz) / C32A
Compressor +
heating cartridge
3~/N/PE 400 V
(50Hz) / C25A
3~/N/PE 400 V
(50Hz) / C25A
3~/N/PE 400 V
(50Hz) / C32A
RCD-Type BBBB
