47
730.138 | 08.12
EN
Defining limits for the heat target
: press button.
The display for setting the limit of the heat target appears.
SET: press button.
"max" flashes in the display (heat target's maximum value).
: set the maximum value.
SET: press button to confirm.
Activating time control
: press button.
The "Time controlled" display appears.
SET: press button.
Time control is activated.
: press button.
The display for setting the duration appears.
SET: press button.
The time value flashes in the display.
: set the time value.
SET: confirm the value and go to the next value.
The settings are saved.
NOTE
The switch-on time must always be before the switch-off time. There-
fore, when the switch-on value is being adjusted, the switch-off value
will also be changed to a later time if necessary. Adjusting the switch-off
value to a time before the switch-on value is blocked.
7.3.9 Time function
This function allows a controller output to be controlled depending on
a pre-defined time range.
Setting the time window
"Functions" submenu selected, see "Selecting a function"
(see chapter 7.3.1).
Time function activated, see "Activating a function" (chapter 7.3.1).
Outputs selected, see "Selecting an output" (chapter 7.3.1).
: press button.
The display for setting the duration appears.
SET: press button.
The time value flashes in the display.
: set the time value.
SET: confirm the value and go to the next value.
The settings are saved.
NOTE
The switch-on time must always be before the switch-off time. There-
fore, when the switch-on value is being adjusted, the switch-off value
will also be changed to a later time if necessary. Adjusting the switch-off
value to a time before the switch-on value is blocked.
✓
✓
✓
