7.2 Systems
The desired solar energy system can be chosen using the "System" submenu. There are a total of 14 dif-
ferent systems to choose from (subdivided into 4 system groups).
System group 14 systems Chapter
Systems with one
storage tank
System 1: 1 collector array – 1 storage tank 7.2.1
System 2: 1 collector array - 1 storage tank - heating return
increase
System 3: 1 collector array - 1 storage tank with external heat
exchanger
System 4: 1 collector array – 1 storage tank with zone loading
System 5: 2 collector arrays (east/west roof) – 1 storage tank
Systems with two
storage tanks
System 6: 1 collector array – 2 storage tanks – intelligent
pump control
7.2.2
System 7: 1 collector array – 2 storage tanks – intelligent valve
control
Systems with a swimming
pool
System 8: 1 collector array – 1 swimming pool 7.2.3
System 9: 1 collector array - 1 swimming pool with external
heat exchanger
System 10: 1 collector array - 1 swimming pool in stand-alone
operation with external heat exchanger
System 11: 2 collector arrays (east/west roof) - 1 swimming
pool
System 12: 2 collector arrays (east/west roof) - 1 swimming
pool in stand-alone operation with external heat
exchanger
Systems with one storage
tank and a swimming
pool
System 13: 1 collector array - 1 storage tank - 1 swimming
pool in stand-alone operation with external heat
exchanger - intelligent pump control
7.2.4
System 14: 1 collector array - 1 storage tank - 1 swimming
pool in stand-alone operation with external heat
exchanger - intelligent valve control
NOTE
Upon selection of a new system, the functions, storage tank priority, and
parameters are automatically returned to their factory settings.
Check the settings again!
