EN-12
8.2
English
Displays the measured flow temperature (R4) during cooling
operation measured at the heat exchanger output
Cooling function
passive
Displays the temperature measured by the hot gas sensor (R18) Reversible HP
Displays the temperature measured in the room in which room
climate control station 1 is installed.
This temperature is the controlled variable for silent cooling in
heating circuit 1/2.
Cooling function
silent cooling
Heating circuit 1/2
or
room regulation
Displays the humidity measured in the room in which room climate
control station 1 is installed. This value is used for calculating the
dew point with silent cooling in heating circuit 1/2.
Cooling function
silent cooling
Heating circuit 1/2
Displays the temperature measured in the room in which room
climate control station 2 is installed.
This value is used for calculating the dew point with silent cooling
in heating circuit 3.
Cooling function
silent cooling
Heating circuit 3
Displays the current humidity in the room in which room climate
control station 2 is installed. This value is used for calculating the
dew point with silent cooling in heating circuit 3.
Cooling function
silent cooling
Heating circuit 3
Indicates whether a cooling request has been made. Even if a
request is pending, it is possible that the heat pump still does not
operate (e.g. frost protection). This block is shown by the
preceding lock symbol
.
Cooling function
cooling
Displays the current domestic hot water set temperature Hot water
sensors
Displays the measured domestic hot water temperature (R3). This
temperature is the controlled variable for DHW preparation.
Hot water
sensor
Indicates whether a request for domestic hot water has been
made. Even if a request is pending, it is possible that the heat
pump still does not operate (e.g. programmed shut-off times,
operating limits, heating up). This block is shown by the preceding
lock symbol
. A HP block combined with a sufficiently high
cylinder temperature is indicated by "Bivalent-renewable".
Hot water
Displays the current swimming pool temperature (R20). This is the
controlled variable.
Swimming pool
sensor
Indicates whether a request for swimming pool water has been
made. Even if a request is pending, it is possible that the heat
pump still does not operate (e.g. programmed shut-off times,
operating limits, heating up). This block is shown by the preceding
lock symbol
. A HP block combined with a sufficiently high
cylinder temperature is indicated by "Bivalent-renewable".
Swimming pool
Displays the temperature measured at the heat source (R6) output
or the refrigerating circuit output of the HP. This temperature
serves to safeguard the lower operating limit.
BW o. WW HP
with integr.
controller
Displays the current pressure (R26) on the high-pressure side. Pressure sensor
Displays the current pressure (R25) on the low-pressure side. Pressure sensor
Display of the heat source temperature (R24) for a reversible heat
pump with electronic expansion valve
BW o. WW HP
Reversible
electronic expa.
valve
Displays the heat source temperature (R24) in combination
systems.
Cooling
Cooling function
Display of sensor and system values Display
