C Save the modified value by
depressing the button .
D Modifying “P61 Anti_Pinch On Cage”,
“F509 Cooling Fan Reverse”, “F510
Transport Mode Enable” and
“F541Engine Hook Open Enable”, is
only valid in condition of power on. It
will return back at the moment of
interruption of power supply.
E It returns back to main interface,
when the button is
depressed.
NOTE:：The modification of transport
mode would be invalid at the moment
of one of the following being activated.
Platform control is chosen.
The degree of chassis inclining
exceeds 5.
The angle of main boom lifting
exceeds 20.
Main boom extends more than
one meter.
exit button
MENU button
5 Basket signal bypass selector
To enable movements from the control
panel on the ground with the red
emergency button pressed from the
platform, keep the selector enabled
together with the enable key activated and
the movement selectors concerned.
6 Engine start-up button
Press the green button to start up/switch
off the engine.
7 Acoustic warning button
To activate the acoustic signal press the
yellow button.
8 Key-operated switch
With the key in position 0 the truck is
switched off: in another position, if brought
to 0 the electric circuit closes, switching off
the truck.
To activate the controls on the ground,
turn the key-operated switch to the icon
representing the truck. To activate the
controls in the platform, turn the
key-operated switch to the position
representing the platform.
9 Turret rotation selector
To rotate the turret counter clockwise, turn
the selector to the LH.
To rotate the turret clockwise, turn the
selector to the RH.
10 Articulate boom lift/extend selector
To extend the articulate boom, move the
selector up.
To retract the articulate boom, move the
selector down.
To lift up the articulate boom, move the
selector up.
To lower the articulate boom, move the
selector down.
The extension is valid when the boom is
lifted up completely.
The operation of lifting down is valid when
the boom is retracted completely.
11 Primary telescopic boom lifting selector
To lift up the primary telescopic boom,
move the selector up.
To lower the primary telescopic boom,
move the selector down.
12 Primary telescopic boom extension
selector
To extend the primary boom, turn the
selector to the LH.
