red emergency stop button to the ON
position by turning it clockwise
15 Hydraulic generator ( optional)
When present, the selector activates the
power socket on the platform to power up
the work tools.
16 Basket signal bypass selector
To enable movements from the control
panel on the platform when something
wrong with the machine happened, keep
the selector enabled together with the
enable key activated and the movement
selectors concerned.
Note: Just when there is some failure
warning except deadly security alarm,
and the machine has to be moved or
loaded, the switch can be used to do,
while the persons in the platform and
around the machine are safe. Arbitrary
usage of the switch will result in
damage and serious injury.
17 Turret rotation /secondary boom lifting
Move the joystick in both horizontal
directions to rotate the turret.
Move the joystick in both vertical
directions to raise/lower the secondary
boom.
18 Secondary telescopic boom (if present)
extension
Not used.
19 Platform rotation
Move the joystick in both horizontal
directions to rotate the platform.
20 Levelling the platform
Not used.
