Operating Instructions
41
Emergency Stowing
Just when there is some failure warning except deadly security alarm and the platform has to be
lowered or loaded, push Bypass Switch up and hold on, and then activate the footswitch and
corresponding switch to complete it.
The fault is divided into three classes: class A/B/C. Different class, different emergency stowing
procedure.
Class A
Item
Fault
Description
1
Load sensor fault
/
2
Angle sensor fault
Because the angle of the main boom cannot be
monitored timely, when there is angle sensor
fault, so that the angle of the main boom is less
than 30 should be confirmed at the diagnostic
panel when lowering the articulate boom.（Switch
the option for angle of the main boom less than
30 to on.）Refer to diagnostic panel for more
information.
3
Length sensor fault
Because the length of the boom cannot be
monitored timely, when there is length sensor
fault, so that the boom completely retraced
should be confirmed at the diagnostic panel when
retracting boom. (Switch the option for main
boom retracted to on.) Refer to diagnostic panel
for more information.
4
Platform angle sensor fault
/
5
Jib levelling angle sensor fault
/
6
Chassis inclining sensor fault
/
7
Power on self test fault
/
8
Pedal switch and redundancy fault
/
9
Differential lock feedback fault
/
10
Articulate boom retracted
completely sensor fault
Because the length of the boom cannot be
monitored timely, when there is articulate boom
retracted completely sensor fault, so that the
boom completely retraced should be confirmed at
the diagnostic panel when retracting boom.
(Switch the option for articulate boom retracted to
on.) Refer to diagnostic panel for more
information.
Lower the platform as the follow procedure when there is one fault or more belonging to class A.
