OPERATOR’S MANUAL with Maintenance Information
Operating Instructions
33
How to use the Safety Arm
The safety arm side of the scissor system
needs to be used for maintenance work. This
safety arm relief the lifting cylinder and they
hold the working platform safe.
1 Raise the platform until the distance of the
two sets of scissor at least 0.9m.
2 Remove the screw and rotate upward to a
vertical position
3 Lower the platform until the safety arm
rests securely on the shaft. Keep clear of
the safety arm when lowering the platform.
Don’t engage the safety arm
unless unload the platform.
Using this safety arm is
necessary during operations near the scissor
system if the platform is lifted!
How to Fold Down the
Guardrails
The platform railing system consists of three
fold down rail section for the extension deck
and three sections for the main deck. All
sections are held in place by four latches.
1 Fully lower the platform and retract the
platform extension.
2 Remove the platform controls.
3 Opening the latches in the corners the rails
have to be folded in correct order of the
numbering.
○
1
○
2
○
5
○
4
○
6
○
3
