OPERATOR’S MANUAL with Maintenance Information
Maintenance
60
Fault State
List of Fault Codes
Display
for
Platform
Display for Ground
Description
Description
01
01 Internal ECU Fault
Main ECU System Fault
Replace Main ECU
02
02 Platform ECU Fault
ECU/Platform Communication
Fault
Check the wiring,
check the
platform/ground control
14
14 Angle Sensor Fault
Angle Sensor Fault
Check the sensor,
check the wiring
15
15 Pressure Sensor Fault
Pressure Sensor Fault
Check the sensor,
check the wiring
20
20 Chassis Start Sw Fault
Chassis Start Switch ON at
power-up
Check the switch,
check the wiring
21
21 Chassis Choke Sw Fault
Chassis Choke Switch ON at
power-up
Check the switch,
check the wiring
22
22 Chassis Up Sw Fault
Chassis Up Switch ON at
power-up
Check the switch,
check the wiring
23
23 Chassis Lift Sw Fault
Chassis Lift Switch ON at
power-up
Check the switch,
check the wiring
24
24 Chassis Down Sw Fault
Chassis Down Switch ON at
power-up
Check the switch,
check the wiring
25
25 Left Turn switch Fault
Platform Left Turn Switch ON at
power-up
Check the switch,
replace the platform
26
26 Right Turn switch Fault
Platform Right Turn Switch ON
at power-up
Check the switch,
replace the platform
27
27 Drive Enable Sw Flt
Platform Drive Enable Switch
ON at power-up
Check the switch,
replace the platform
28
28 Off Neutral Drive Joystick
Platform Joystick not in neutral
ON at power-up
Check the switch,
replace the platform
31
31 Platform Choke Sw Fault
Platform Choke Switch ON at
power-up
Check the switch,
replace the platform
32
32 Platform Start Sw Fault
Platform Start Switch ON at
power-up
Check the switch,
replace the platform
33
33 Left Front outrig Sw Flt
Platform Left Front Outrigger
Enable Switch ON at power-up
up
Check the switch,
replace the platform
34
34 Right Front outrig Sw Flt
Platform Right Front Outrigger
Enable Switch ON at power-up
Check the switch,
replace the platform
35
35 Left Rear outrig Sw Flt
Platform Left Rear Outrigger
Enable Switch ON at power- up
Check the switch,
replace the platform
36
36 Right Rear outrig Sw Flt
Platform Right Rear Outrigger
Enable Switch ON at power-up
Check the switch,
replace the platform
