DINGLI JCPT2212DC - Page 66

OPERATOR’S MANUAL with Maintenance Information
Maintenance
61
Display
for
Platform
Display for Ground
Description
Repair
37
37 Auto Level Switch Fault
Platform Outrigger Auto Level
Enable Switch ON at power-up
Check the switch,
replace the platform
38
38 LF OR Limit Switch Fault
Left Front Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
39
39 RF OR Limit Switch Fault
Right Front Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
40
40 LR OR Limit Switch Fault
Left Rear Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
41
41 RR OR Limit Switch Fault
Right Rear Outrigger Limit
Switches are both ON
Check the limit switch,
check the wiring
44
44 Down Limit Switch fault
Down Limit Switch fault
Check the limit switch,
check the wiring
45
45 Platform Ret Coil Fault
Platform Retract Coil Fault
check the wiring,
replace the valve
46
46 Platform Ext Coil Fault
Platform Extend Coil Fault
check the wiring,
replace the valve
47
47 Steer Switch Coil Fault
Steer Switch Coil Fault
check the wiring,
replace the valve
48
48 Pothole Ret Coil Fault
Pothole Retract Coil Fault
check the wiring,
replace the valve
49
49 Pothole Ext Coil Fault
Pothole Extend Coil Fault
check the wiring,
replace the valve
50
50 Outrigger Fault
Outdoor Mode ： Outrigger not
Extend.
Or all four Outriggers are not
Extend.
check the outdoor
mode,
check the limit switch,
check the wiring,
replace the valve
54
54 Up Coil Fault
Power FET, channel DOWN
fails
check the wiring,
replace the valve
55
55 Down Coil Fault
Power FET, channel RT fails
check the wiring,
replace the valve
56
56 Right Turn Coil Fault
Power FET, channel LT fails
check the wiring,
replace the valve
57
57 Left Turn Coil Fault
Power FET, channel LT fails
check the wiring,
replace the valve
60
60 RR MC Alarm
Rear right Motor controller Alarm
check the wiring,
replace the controller
61
61 RL MC Alarm
Rear left Motor controller Alarm
check the wiring,
replace the controller
62
62 FL MC Alarm
Front left Motor controller Alarm
check the wiring,
replace the controller
63
63 FR MC Alarm
Front right Motor controller
Alarm
check the wiring,
replace the controller
