OPERATOR’S MANUAL with Maintenance Information
Maintenance
62
Display
for
Platform
Display for Ground
Description
Repair
68
68 Low Battery Voltage
Low Battery Voltage
check the wiring,
check the battery
70
70 RR MC Warning
Rear right Motor controller
Warning
check the wiring,
replace the controller
71
71 RL MC Warning
Rear left Motor controller
Warning
check the wiring,
replace the controller
72
72 FL MC Warning
Front left Motor controller
Warning
check the wiring,
replace the controller
73
73 FR MC Warning
Front right Motor controller
Warning
check the wiring,
replace the controller
81
81 Left Front Otrg Coil Flt
Power FET, channel LEFT
FRONT OUTRIGGER fails
check the wiring,
replace the valve
82
82 Left Rear Otrg Coil Flt
Power FET, channel LEFT
REAR OUTRIGGER fails
check the wiring,
replace the valve
83
83 Right Front Otrg Coil Flt
Power FET, channel RIGHT
FRONT OUTRIGGER fails
check the wiring,
replace the valve
84
84 Right Rear Otrg Coil Flt
Power FET, channel RIGHT
REAR OUTRIGGER fails
check the wiring,
replace the valve
85
85 Outrigger Ext Coil Fit
Power FET, channel EXTEND
OUTRIGGER fails
check the wiring,
replace the valve
86
86 Outrigger Ret Coil Fit
Power FET, channel RETRACT
OUTRIGGER fails
check the wiring,
replace the valve
90
90 RR MC Comm Fault
Rear right Motor controller
communication fault.
check the wiring,
replace the controller
91
91 RL MC Comm Fault
Rear left Motor controller
communication fault.
check the wiring,
replace the controller
92
92 FL MC Comm Fault
Front left Motor controller
communication fault.
check the wiring,
replace the controller
93
93 FR MC Comm Fault
Front right Motor controller
communication fault.
check the wiring,
replace the controller
97
97 Wheels not centered
The wheel is out of center when
lifting
Turn the wheel back
to the center.
99
99 Pothole Fault
Pothole Fault
Check the limit switch,
check the wiring
OL
Platform Overload
Platform Overload Fault
Remove the excess
load immediately.
LL
Chassis Tilt
Machine Tilted Beyond Safe
Limits Fault
check the wiring,
replace the sensor
For more information, please consult the appropriate Dingli Service Dept.
