DINGLI JCPT2223RTB - Legend; Component Identification

OPERATOR’S MANUAL with Maintenance Information
Legend
8
Legend
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1 Platform entry gate
9 Engine(behind cover)
2 Manual storage containers
10 Rear wheel
3 Platform controls
11 Hydraulic tanks、Fuel tanks (behind cover)
4 Main Platform
12 Lift Cylinder
5 Lanyard anchorage point
13 Ground controls
6 Platform guard rails
14 Front wheel
7 Platform extensions
15 Outrigger
8 Scissor Arms
16.Entry ladder
