DINGLI JCPT2223RTB User Manual

OPERATOR’S MANUAL with Maintenance Information
Specifications
14
Model JCPT2223RTB
Height, working maximum
22m
Height, platform maximum
20m
Height, stowed maximum
Rails up
3.86m
Height, stowed maximum
Rails folded
3.0m
Width
2.46m
Length, platform retracted
4.95m
Platform dimensions
Platform length x width
4.59m×2.25m
Platform extension length
2.7m
Maximum load capacity
750kg
Maximum wind speed
12.5m/s
Wheelbase
3.3m
Turning radius (outside)
3.4m
Turning radius (inside)
1.25m
Ground clearance
40cm
Weight
See Serial Label
Machine weights vary with option configurations
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic pressure
(functions)
240bar
Tire size
36×14-20
Airborne noise emissions
<80 dB
Maximum sound level at normal operating
workstations (A-weighted)
Vibration value does not exceed 2.5m / s
2
Maximum slope rating ,
Stowed position
30%
Maximum side slope rating
Stowed position
30%
Note: Slope rating is subject to ground
conditions and adequate traction.
Maximum working slope
X-2°, Y-3°
Drive speeds
Stowed, maximum
4.5 km/h
Platform raised, maximum
0.4 km/h
Floor loading information
Tire load, maximum
4030kg
Outrigger load, maximum
4030kg
Tire contact pressure
740kPa
Occupied floor pressure
11.8kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
