OPERATOR’S MANUAL with Maintenance Information
Decals
10
Decal Inspection
Use the pictures on the next page to verify that all decals are legible and in place.
Below is a numerical list with quantities and descriptions.
No. Part No. Description Qty. Remark
1 09440011 Decal, Label-Lanyard anchorage point 4
2 09340001 Decal, Notice-Keep the manual with the machine 1
3 09440001 Decal, Danger-General safety rules 1
4 09440003 Decal, Danger-Tip-over hazard, tilt-alarm 1
5 09340003
Decal, Instructions-Refer the operator to the
instructions for use
2
6
09440013 Decal, Label-Capacity 380kg 1 S0608EH/S0608E
09440014 Decal, Label-Capacity 230kg 1 S0808EH/S0808E
09440015 Decal, Label-Capacity 450kg 1 S0812EH/S0812E
09440016 Decal, Label-Capacity 320kg 1 S1012EH/S1012E
09440017 Decal, Label-Capacity 320kg 1 S1212EH/S1212E
09440038 Decal, Label-Capacity 250kg 1
S1412-EHXC/S1412
-EXC
7 09440005 Decal, Warning-Use indoors only 1
S0808EH/S0808E
S1212EH/S1212E
S1412-EHXC/S1412
-EXC
8 09210015 Nameplate, Manufacturer serial number 1
9 09310001 Decal, Instructions-Forklift pockets 2
10 09310003 Decal, Instructions-Tie down point 4
11 09310002 Decal, Instructions-Lift point 4
12
09310008
Decal, Instructions-Maximum wheel load: 1000kg 4 S0608EH/S0608E
09310010 Decal, Instructions-Maximum wheel load: 960kg 4 S0808EH/S0808E
09310012 Decal, Instructions-Maximum wheel load: 1240kg 4 S0812EH/S0812E
09310014 Decal, Instructions-Maximum wheel load: 1310kg 4 S1012EH/S1012E
09310016 Decal, Instructions-Maximum wheel load: 1280kg 4 S1212EH/S1212E
09310018 Decal, Instructions-Maximum wheel load: 1350kg 4
S1412-EHXC/S1412
-EXC
To Next Page
