DINGLI S1412-EXC - Page 88

OPERATOR’S MANUAL with Maintenance Information
Schematic
84
S0608E S0808E S0812E
120bar
RV1=130bar(S0608E)
RV1=160bar(S0808E)
RV1=210bar(S0812E)
Lift cylinder
Platform loading
（ Option ）
Steer cylinder
P
M
SV2
FRRV1
SV1
S1 S2
L
T
Tank
Pump
5802-3.2-14
Function valve DPH-0918-10
1mm
1mm
1.5mm
Lower valve
NBCY-1001A-11
